imensions Drawings
e :Calmping thickness:1 to 6 mm/0.04 to 0.24 in.
Mounting and Clearance
Mounting
Diameter of Finished Fixing Holes
(1)Minimum value.(2)40 mm/1.58 in. for Emergency switching off pushbutton only.
(3)Standard value: Ø 22.3 (0; + 0.4) mm/Ø 0.88 (0; + 0.02) in.
Connections and Schema
Wiring Diagram
(1)LED
